Technical Specification :
Rated Voltage | KV | 12 | 24 | 36 | ||
With Stand Voltage | On Power - Frequency 50 Hz For 1min | To Earth | KV | 38 | 50 | 70 |
Between Terminals | KV | 45 | 60 | 80 | ||
Impulse 1.2/50 u sec | To Earth | KV | 95 | 125 | 170 | |
Between Terminals | KV | 110 | 145 | 195 | ||
With Stand Current | Rate Current | A | 400 |
| 630 | |
Short-time Current For 1 Sec | KA | 12.5 |
| 16 | ||
Peak Current | KA | 32 |
| 40 | ||
Breaking Capacity for active Circuits (cos% = 0.8) | A |
|
| 10 | ||
For No. - Load Transformers | A |
|
| 1 | ||
For No. - Load Lines and cables | A | 5 |
|
|
|
